Innovative U-Shaped Transparent Display for High-Impact Visual Experiences
The 48 Inch Custom Shell See-Through Screen U-Shaped Floor Standing Transparent OLED Display is a premium commercial visualization solution designed for retail stores, exhibition halls, museums, brand experience centers, and interactive marketing environments. Unlike traditional flat signage, this transparent OLED display features a unique U-shaped enclosure design that surrounds the viewing area, creating a highly immersive and spatial digital storytelling experience.
With self-emissive OLED technology and transparent display characteristics, digital content appears to float within a semi-open structure, allowing physical products or installations to remain visible behind the screen.
| 48 Inch U-shaped floor-standing OLED transparent screen(ZXTLCD-T48-LP6A) |
| LCD Panel Parameters |
| Screen Size |
48 inch |
| Panel type |
OLED |
| Resolution |
1920*540 |
| Brightness |
150-400cd/m² Automatic adjustment |
| Contrast Ratio |
200000:1 |
| Viewing angle(up/down/left/right) |
178°(H)/178°(V) |
| Response Time |
1ms(Gray To Gray) |
| Display color |
10bit(R),1.07 billon colors |
| Onboard interface |
| Input Interface |
Type-c*1 USB*2 HDMI*2 RJ45*1 WIFI*2 Bluetooth*1 TOUCH USB*1 |
| Output interface |
RS232 |
| Touch Method |
| Capacitive Touch screen |
Default 10 points Capacitive Touch |
| Power Specifications |
| Power supply |
AC 100-240V |
| Total System Power Consumption |
<200W |
| Machine Operating Parameters |
| running time |
7*12h |
| Screen life |
30000h |
| Operating temperature |
0℃~40℃ |
| Operating Humidity |
20%~80% |
| structure |
| Material |
Aluminum+Tempered Glass |
| external dimensions |
2000*510*450(mm) |
| Overall dimensions |
TBD |
| Installation Method |
Integrated base |
| Net weight / Gross weight |
TBD |
| Accessories |
| Power cord, antenna, remote control, certificate of conformity and warranty card |
| other |
| After-Sales Service |
1-Year Warranty |
Designed for Immersive U-Shaped Commercial Installations
Unique U-Shaped Structure for 360° Visual Engagement
The standout feature of this display is its custom U-shaped design, which enhances multi-angle visibility and creates a semi-enclosed immersive space. This structure is ideal for attracting attention in open commercial environments such as shopping mall atriums, exhibition booths, and flagship retail stores.
The U-shaped layout guides the viewer’s attention naturally toward the center, making it highly effective for product storytelling and brand presentations.
500 Nits Brightness for Indoor Visibility
With up to 500 nits brightness, the display ensures clear visibility in indoor commercial environments. Combined with OLED self-emissive technology, it delivers strong contrast, vivid colors, and stable image performance even under complex lighting conditions.
Premium Transparent OLED Performance
The display supports Full HD resolution, wide color gamut, and fast refresh rate, ensuring smooth and high-quality visual output. Its transparent structure allows physical objects placed inside or behind the U-shaped frame to remain visible, creating a layered visual experience that blends real and digital content seamlessly.
Compared with traditional LED or LCD installations, it offers a more futuristic, lightweight, and premium aesthetic suitable for high-end branding environments.
H2: Ideal Applications
This transparent digital signage solution is widely used in:
- Luxury retail brand showcases
- Shopping mall immersive advertising zones
- Exhibition and trade show installations
- Museum interactive display spaces
- Automotive brand experience centers
- Technology product launch events
- Corporate lobby branding installations
- High-end commercial visual storytelling setups
FAQ
What is a U-shaped transparent OLED display?
It is a custom-designed OLED display structure shaped in a U-form, allowing immersive multi-angle viewing and enhanced spatial presentation.
What is the benefit of 500 nits brightness?
It ensures clear visibility in indoor environments, especially in retail and exhibition spaces with mixed lighting conditions.
Can it be customized?
Yes. The shell structure, dimensions, and display configuration can be customized according to project requirements.
Conclusion
The 48 Inch Custom U-Shaped Floor Standing Transparent OLED Display delivers a powerful combination of immersive structure design, transparent OLED technology, and high-brightness performance. It enables brands to create visually striking, spatially engaging, and highly memorable commercial display experiences.
